Robotics & Mechatronics 2: 3D Modelling & Machine Design

This course is all about Industrial Machine Design From Scratch using Fusion 360 (Free CAD Software)

Unlike other 3D CAD Courses which focuses on the Design Tool Functions, we will be focusing on Real-Life Machine Building with the utter most details, From Screws, Nuts, and Frames, ending with full Scale Machine.

All Machines we are designing are the most common machines in Small/Large Factories. And they form an essential role in almost any production line.

Here is a summary of what we will be designing :

• Cartesian 3-Axis Robot

• Pick & Place Machine

• Single-Axis Linear Motion

• Distribution/Accumulation Turntable

• Single-Axis Piston Rejection Mechanisms

• Flat Conveyor Belts

• Modular Conveyor Belts

• There one section that will introduce you to all Necessary Fusion 360 Functions

By the end of this course you should be able to:

• Design Motion and Mechanical Concept for any machine you have in mind

• Understand the actual Mechanical Parts involved in Real-Life Machines

• Understanding the Most common machines used in actual Production Lines and Factories

• If you are a PLC Programmer, then this course will also help you debug mechanical issues because of the understanding you will gain regarding Mechanical Parts and motion

• Being able to design anything using one of the most famous CAD tools out there, Fusion 360

___________________________

This is Part 2/5 of the Robotics & Mechatronics Series, Which main purpose is to help you Master the following Path:

1. Course 1: Understand Mechanical Design Theory for Machines & Production Lines

2. Course 2: Designing, Hands-On, Real Industrial Mechanical Machines with Utter most Details

3. Course 3: Digital Twinning, and Actually Animate & Physically Simulate your 3D CAD Designs

4. Course4: PLC Control Mechanical Designs & Digital Twin using Algorithms

5. Course5: Hands-On Building & Controlling All your designs in Real-Life
